Product Introduction:
Lead-acid replacement UPS lithium battery
PLB’s conventional voltage UPS battery is a battery pack specially designed to replace lead-acid batteries in general UPS equipment, suitable for UPS with similar voltage range lead-acid batteries on the market.
Application scenarios:
Data centers, enterprise computer rooms, supermarkets, building systems, etc.
LiFePO4 battery cells with high stability, safety and reliability.
Equipped with RS232 and RS485 communication interfaces.
Intelligent BMS: Overcharge/over-discharge/over-temperature/over-current/short-circuit protection functions to ensure battery safety and reliability.
High rate discharge: supports up to 7.5C discharge.
Floating charge: floating charge design.
Small size: about 2/3 the size of lead-acid battery.
Light weight: about 1/3 the weight of lead-acid battery.
Long life: 4-5 times longer than lead-acid batteries, with a calendar life of more than 10 years.
Easy to expand: supports up to 4 series battery packs and 10 parallel battery packs.
12.8V 6Ah Output Power 0.5KVA LiFePO4 UPS Battery – Product Description:
| Electrical specifications | |
| Nominal voltage | 12.8V |
| Nominal capacity | 6Ah |
| Power | 76.8Wh |
| Internal resistance | 30MΩ |
| Self-discharge | < Single month 1％ |
| Series and parallel | 4S10P |
| UPS compatible | ≤0.5KVA |
| Mechanical specifications | |
| Cells | IFR26650-3000mAh |
| Number of cells in series | 4S2P |
| Dimensions (L x W x H) | 150*68*94mm |
| Weight | 1Kg |
| Output terminals | MR30PW-M |
| Casing material | ABS+PC |
| IP rating | IP65 |
| Discharge specifications | |
| Backup time | 8~15Mins |
| Maximum continuous discharge current | 45A |
| Over discharge protection voltage | 9.2V |
| Over discharge recovery voltage | 10.8V |
| Short circuit protection | Yes |
| Charging specifications | |
| Charging current | 6A |
| Charging voltage | 14.4V |
| Overcharge protection voltage | 14.6V |
| Overcharge recovery voltage | 14.2V |
| Balanced start voltage | 14V |
| Temperature specifications | |
| Discharge temperature | -20-60℃ |
| Charge temperature | 0-45℃ |
| Storage temperature | -5-45℃ |
| BMS over-temperature protection | 65±5℃ |
| BMS over-temperature protection recovery | 55±5℃ |
| Communication | |
| Communication | SMBUS(Optional) |
| Compliance | |
| Certification | UN 38.3 |
